Lantech IES-3408GSFP is a high performance L2+ (Gigabit uplink) switch with 8 10/100TX + 4 1000M SFP which provides L2 wire speed and advanced security function for network aggregation deployment. It delivers ITU G.8032 enhanced ring recovery less than 20ms in single ring while also supports train ring, enhanced mode, multiple VLAN model with easy configuration. The comprehensive QoS, QoS by VLAN, advanced security including INGRESS/EGRESS ACL L2/L3, TACACS+**, SSH v2/SSL, Mac based DHCP server, DHCP Option 82, DHCP server, IGMPv1/v2/v3/router port, QinQ are supported and also required in large network. It also supports Cisco Discovery Protocol (CDP) for Ciscoworks to detect the switch info and show on L2 map topology.
Miss-wiring avoidance, Loop protection, Node failure protection
The IES-3408GSFP also embedded several features for stronger and reliable network protection in an easy and intuitive way. When the pre-set ring configuration failed or looped by miss-wiring, Lantech IES-3408GSFP is able to alert with the LED indicator and disable ring automatically. Node failure protection ensures the switches in a ring to survive after power breakout is back. The status can be shown in NMS when each switch is back. This feature prevents the broken ring and keep ring alive without any re-configuration needed. Loop protection is also available to prevent the generation of broadcast storm when a dumb switch is inserted in a closed loop connection.
DHCP option 82 & Port based, Mac based DHCP, Option66, DHCP Snooping, IPv6 DHCP server
DHCP server can assign dedicated IP address by MAC or by port (Port based for single switch) , it also can assign IP address by port for multiple switches with single DHCP option82 server. DHCP Snooping is supported. For the ending device which need to download file from TFTP server, DHCP Option66 server can offer IP address of TFTP server to DHCP client. Basic IPv6 DHCP service can be supported.
User friendly GUI, Auto topology drawing
The user friendly UI, innovative auto topology drawing and topology demo makes IES-3408GSFP much easier to get hands-on. The complete CLI enables professional engineer to configure setting by command line.
Enhanced G.8032 ring, 16 MSTI MSTP; MRP ring
Lantech IES-3408GSFP features enhanced G.8032 ring which can be self-healed in less than 20ms for single ring topology protection covering Multicast packets. It also supports various ring topologies that covers double ring, multi-chain (under enhanced ring), train ring, basic ring, multiple-VLAN ring and auto-ring by easy setup than others. The innovative auto-Ring configurator (auto mode) can calculate owner and neighbor in one step. It supports MSTP that allows RSTP over VLAN for redundant links with 16 MSTI.
MRP (Media Redundancy Protocol) can be supported for industrial automation networks.
Editable configuration file
The configuration file of Lantech IES-3408GSFP can be exported and edited with word processor for the other switches configuration with ease. The factory reset button can restore the setting back to factory default and built-in watchdog design can automatically reboot the switch when CPU is found dead.
QoS by VLAN for legacy device
QoS by VLAN can allow switch to tag QoS by VLAN regardless the devices acknowledge QoS or not in which greatly enhance the bandwidth management in a network.
QinQ, QoS and GVRP supported
It supports the QinQ, QoS, GVRP for large VLAN segmentation.
802.1X security by MAC address
MAC-based port authentication is an alternative approach to 802.1x for authenticating hosts connected to a port. By authenticating based on the host's source MAC address, the host is not required to run a user for the 802.1x protocol. The RADIUS server that performs the authentication will inform the switch if this MAC can be registered in the MAC address table of switch.
IGMPv3,GMRP, router port, MLD Snooping, static multicast forwarding and multicast Ring protection
The unique multicast protection under enhanced G.8032 ring can offer immediate self-recovery instead of waiting for IGMP table timeout. It also supports IGMPv3, GMRP, router port, MLD snooping and static multicast forwarding binding by ports for video surveillance application.
Event log & message; 2DI / 2DO
In case of event, the IES-3408GSFP is able to send email to pre-defined addresses as well as SNMP Traps out immediately. It provides 2DI and 2DO. When disconnection of the specific port was detected; DO will activate the signal LED to alarm. DI can integrate the sensors for events and DO will trigger the alarm while sending alert information to IP network with email and traps.
Optional environmental monitoring** for switch inside information (-M model)
The environmental monitoring can detect switch overall temperature, voltage and current where can send the SNMP traps, email when abnormal.
Wide range dual DC powered input with galvanic isolation; Relay contact alarm, High ESD protection
The Lantech IES-3408GSFP is designed with dual power supply at 12/24/48VDC (9.5~60VDC) or single power supply at 90~305VAC/120~430VDC. Featured with relay contact alarm function, the IES-3408GSFP is able to connect with alarm system in case of power failure. The IES-3408GSFP also provides ±2000V EFT/SURGE and ±4000 VDC (Contact) / ±8000 VDC (Air) Ethernet ESD protection, which can reduce unstable situation caused by power line and Ethernet.
Industrial hardened design for extended temperature operation
Lantech IES-3408GSFP features high reliability and robustness coping with extensive EMI/RFI phenomenon, environmental vibration and shocks usually found in factory, substation, steel automation, aviation, mining and process control. It is the best solution for Automation, transportation, surveillance, Wireless backhaul, Semi-conductor factory and assembly lines.
The -E model can be used in extreme environments with an operating temperature range of -40°C to 75°C
|8350-530||IES-3408GSFP||4 1000 SFP + 8 10/100TX L2+ Industrial Managed Ethernet Switch; -20°C to 60°C; Dual 9.5~60VDC|
|8350-531||IES-3408GSFP-E||4 1000 SFP + 8 10/100TX L2+ Industrial Managed Ethernet Switch; -40°C to 75°C; Dual 9.5~60VDC|
|8350-532||IES-3408GSFP-M||4 1000 SFP + 8 10/100TX L2+ Industrial Managed Ethernet Switch; -20°C to 60°C; Environmental monitoring; Dual 9.5~60VDC|
|8350-533||IES-3408GSFP-M-E||4 1000 SFP + 8 10/100TX L2+ Industrial Managed Ethernet Switch; -40°C to 75°C; Environmental monitoring; Dual 9.5~60VDC|
|8350-528||IES-3408GSFP-HV||4 1000 SFP + 8 10/100TX L2+ Industrial Managed Ethernet Switch; -20°C to 60°C; Single 90~305VAC/120~430VDC|
|8350-529||IES-3408GSFP-HV-E||4 1000 SFP + 8 10/100TX L2+ Industrial Managed Ethernet Switch; -40°C to 75°C; Single 90~305VAC/120~430VDC|
|8350-5281||IES-3408GSFP-HV-M||4 1000 SFP + 8 10/100TX L2+ Industrial Managed Ethernet Switch; -20°C to 60°C; Environmental monitoring; Single 90~305VAC/120~430VDC|
|8350-5291||IES-3408GSFP-HV-M-E||4 1000 SFP + 8 10/100TX L2+ Industrial Managed Ethernet Switch; -40°C to 75°C; Environmental monitoring; Single 90~305VAC/120~430VDC|
|MDR-40 Series||40W Single Output Industrial Din Rail Power; 85-264VAC / 120-370VDC Input Range; Cooling by free air convection; RoHS2 ; Operating Temp. -20°C~70°C (ambient, derating each output at 4% per degree from 60°C ~ 70°C)|
|MDR-20 Series||20W Single Output Industrial Din Rail Power; 85-264VAC / 120-370VDC Input Range; Cooling by free air convection; RoHS2 ; Operating Temp. -20°C~70°C (ambient, derating each output at 2.5% per degree from 50°C ~ 70°C)|
|Model name||Description||Model name||Description|
|8330-162-V1||MINI GBIC 1000SX (LC/0.5KM) Transceiver||8330-196-V1||1.25Gbps BiDi SFP 2KM Transceiver (WDM 1550)|
|8330-163-V1||MINI GBIC 1000SX2 (LC/2KM) Transceiver||8330-188-V1||1.25Gbps BiDi SFP 10KM Transceiver (WDM 1310)|
|8330-165-V1||MINI GBIC 1000LX (LC/10KM) Transceiver||8330-189-V1||1.25Gbps BiDi SFP 10KM Transceiver (WDM 1550)|
|8340-0591-V1||MINI GBIC 1000LHX (LC/40KM) Transceiver||8330-186-V1||1.25Gbps BiDi SFP 20KM Transceiver (WDM 1310)|
|8330-166-V1||MINI GBIC 1000XD (LC/50KM) Transceiver||8330-187-V1||LTSFP-1000BX-20KM Transceiver (WDM 1550)|
|8330-169-V1||MINI GBIC 1000XD (LC/60KM) Transceiver||8330-180-V1||LTSFP-1000BX-40KM Transceiver (WDM 1310)|
|8330-167-V1||MINI GBIC 1000ZX (LC/80KM) Transceiver||8330-182-V1||LTSFP-1000BX-40KM Transceiver (WDM 1550)|
|8330-170-V1||MINI GBIC 1000EZX (120KM) Transceiver||8330-181-V1||LTSFP-1000BX-60KM Transceiver (WDM 1310)|
|8330-168-V1||MINI GBIC 10/100/1000T (100m) Transceiver||8330-183-V1||LTSFP-1000BX-60KM Transceiver (WDM 1550)|
|8330-197-V1||1.25Gbps BiDi SFP 0.5KM Transceiver (WDM 1310)||8330-184-V1||LTSFP-1000BX-80KM Transceiver (WDM 1490)|
|8330-198-V1||1.25Gbps BiDi SFP 0.5KM Transceiver (WDM 1550)||8330-185-V1||LTSFP-1000BX-80KM Transceiver (WDM 1550)|
|8330-195-V1||1.25Gbps BiDi SFP 2KM Transceiver (WDM 1310)||All SFP P/N# ended with D are with DDM function|
